Extreme Network 25GBASE-SR (Lite FEC) Multimode Fiber Module

Name: Extreme 25GBASE-SR | Lite FEC 100m MMF Transceiver
Brand: Extreme Networks
Availability: InStock

The Extreme Networks 25GBASE-SR (Lite FEC) SFP28 transceiver is designed for 25G Ethernet over multimode fiber. Supporting Lite Forward Error Correction, it ensures reliable data transmission up to 100 meters on OM4 fiber, making it suitable for high-performance networking environments.

Datasheet

Categories: Extreme Networks 25Gb SFP28 Modules, Extreme Networks Optical Transceivers and Cables, Extreme Networks Switches, Extreme Networks Universal Switches

Description

The Extreme Networks 25GBASE-SR (Lite FEC) SFP28 transceiver delivers high-speed 25G Ethernet connectivity over multimode fiber (MMF). Utilizing an 850nm VCSEL transmitter and PIN photodiode receiver, it supports data rates up to 25.78125Gbps.

With Lite Forward Error Correction (FEC), the module enhances data integrity and transmission reliability. It offers a maximum reach of 100 meters on OM4 fiber and 70 meters on OM3 fiber. The transceiver features Digital Diagnostic Monitoring (DDM) for real-time performance tracking and consumes less than 1W of power.

Compliant with IEEE 802.3by standards, it operates within a commercial temperature range of 0°C to 70°C. The 25GBASE-SR (Lite FEC) transceiver is ideal for data centers and enterprise networks requiring efficient and reliable short-range 25G connectivity.
