The Hikvision DS-K1104 Series sets itself apart by integrating a 2.8″ LCD screen with a keypad and card reader into one access control device. This series supports MIFARE or EM cards and includes a 12-key keypad for PIN-based authentication. The addition of an LCD display enhances user interaction, showing card information, instructions, and prompts for a seamless access experience.
Built with PC+ABS housing and PMMA front panel, the unit is IP64 rated for dust and splash protection, suitable for indoor and semi-outdoor environments. Communication is enabled via RS-485 and Wiegand (W26/W34), allowing for smooth integration into existing security networks.
Visual and audio feedback is provided by onboard LED indicators and a buzzer, while anti-tamper capabilities ensure physical security. Measuring 132 x 92 x 20 mm, it fits standard mounting boxes, and operates in temperatures ranging from -20C to +65C. Power consumption remains efficient at 2W with 12VDC input.
The DS-K1104 Series combines high functionality with sleek aesthetics, making it ideal for commercial, residential, and institutional applications that require advanced user interaction and two-factor authentication.
