The Hikvision DSPEA4L7 Master Panic Station serves as the central command interface for emergency alarm networks in environments such as campuses, hospitals, malls, and transit hubs. Its intuitive 7color capacitive touchscreen provides real-time display of emergency calls, live video feeds, and voice intercom. Designed to scale, it supports management of up to 256 connected panic units.
Key highlights:
Touchscreen UI with flat-design modern interface and real-time alarm logging
Video preview of connected stations with VGA and HDMI output for large displays
Voice intercom via handset, built-in mic, and speakers with audio compression (16/64 Kbps)
Versatile connectivity: dual 10/100/1000 Mbps Ethernet, TCP/IP, SIP-HIK, RTSP, RS485, USB, SD slot ( 128 GB)
Compact form (436 ? 215 ? 67 mm), 12 V DC power, and 10 W power use, operating ?10 ?C to +50 ?C, 10?90% RH
Ideal for use in central monitoring rooms, this master station orchestrates all panic calls network-wide, enables centralized communication, incident logging, and central broadcast?creating a unified emergency system.
