The Honeywell Evacpro-G2 is a versatile 16-zone voice alarm controller tailored for public address and voice evacuation applications. It serves as a local control panel interfacing between field devices like loudspeakers and local audio sources. The unit boasts 16 emergency inputs (15 zone-wise and 1 for all zones) and 16 loudspeaker circuits, allowing for targeted or collective announcements. Equipped with a digital signal processor, it stores and plays pre-recorded emergency messages to alert or evacuate designated zones.
Integration with fire alarm panels is streamlined through potential-free contact closures, enabling automatic activation of evacuation messages. The built-in media player supports USB, SD card, MP3, WAV, FLAC formats, Bluetooth v5.0, and FM radio, offering flexibility in audio sources. The Evacpro-G2 also includes a 4-pin DIN condenser microphone input with N/C contact, balanced and unbalanced line outputs, and supports RS485 communication for remote paging microphones with zone selection.
Technical specifications include a frequency response of 20Hz to 20KHz, total harmonic distortion of 0.01%, and a signal-to-noise ratio exceeding 80dB. The unit operates on 210~240 Volts AC at 50Hz, consuming 80 watts, and is housed in a 19? 2U rack-mountable chassis measuring 540 x 577 x 250 mm and weighing 10.6 kg.
